PERFORMANCE
TECHNICAL DOCUMENTATION & CERTIFICATION

PRODUCT DESCRIPTION

COOL-LITE® SKN 154 and SKN 154 II are high-performance solar control glasses, meeting neutral aesthetic and technical requirements. The perfectly coordinated combination of good solar control, high light transmission and excellent thermal insulation ensures unrestricted comfort in the room at any time of the year.

COOL‑LITE® SKN 155 and 155 II are the next European generation of the current COOL‑LITE® SKN 154 and 154 II, offering improved performance and refined aesthetics. The current products will be gradually phased out across Europe with a smooth, managed transition to ensure seamless continuity.

BENEFITS & APPLICATIONS

The color-neutral character of COOL-LITE^® SKN solar control glass achieves particularly natural lighting effects - both inside and out.

In double-glazing, COOL-LITE^® SKN 154 (II) blocks 72% of solar energy, while letting 52% of light going through the glazing*, leading to the following benefits:

Energy saving, by reducing air-conditioning costs during sunny periods. In winter, it offers the exceptional performance of thermal insulation for greater comfort.
Increased daylight, all year round by making wider glazing possible.
Aesthetic with neutral colour tint and subtle level of reflection.

COOL-LITE^® SKN 154 and SKN 154 II lend themselves to a wide range of applications in new buildings and renovations:
•   Offices
•   Hospitals
•   Schools
•   Sport centers
•   Stores
•   Restaurants
•   Large glazings and bay windows facing south or west.
•   Skylights and conservatory roofs
•   Double Skin Façades (DSF)

*in standard 6/16/4 mm DGU configuration, with coating on face #2, according to EN410

COOL-LITE^® SKN 154 (II) is also available on ORAÉ^® low-carbon glass, to combine performance and sustainability and provide the best of both embodied and operational carbon levels.

This product is covered by a verified Environmental Product Declaration (EPD) and is Cradle to Cradle Certified^® V4.0 Bronze.

APPEARANCE

COOL-LITE^® SKN 154 & 154 II o¬ffer colour neutrality whatever the viewing angles, and a low reflection level with outstanding performances.

TECHNICAL INFORMATION

RANGE

SUBSTRATE: PLANICLEAR^® (clear glass)
DIAMANT^® (extra clear glass)
ORAÉ^® (low-carbon glass)

THICKNESS: From 4 mm to 10 mm
To-be-tempered version up to 12 mm

SIZE: Standard size (Jumbo 3.21 x 6.00 m)
Standard stock size
Overlength (up to 18 m, for to-be-tempered version)

PROCESSING

ANNEALED: The product is available in Annealed version.
HEAT-TREATMENT: The product is available in To-be-tempered version (with suffix II); It is delivered in standard with EASYPRO^® temporary surface protection. To achieve its performance and aesthetics, the product must be tempered. It is compatible with Heat Soak Test.
EDGE DELETION: Edge deletion of the coating is compulsory prior to assembling.
INSULATED GLAZING UNIT: The product must be assembled into an insulated glazing unit (IGU); The coating must be positioned on the face 2 (inside the IGU).
LAMINATION: The product can be laminated, taking care to place the coating outside of the laminate (coating on face 4 of the laminated pane). Consult us for the list of coating validated in contact with the interlayer.
BENDING: The to-be-tempered version of the product (II) can be bent. Bending results depend on the process/technology used; trials should be done for validation.
ENAMELING: No common approval for the enameling of silver-based high-performance coatings.
Annealed and the to-be-tempered versions of the product offer similar performances and aesthetic with a good compatibility in outdoor reflection. Contact us for more details.
