COOL-LITE® KN 166 II & KN 166 A&T AMBIANCE
THE BALANCED TOUCH OF THE URBAN PERSPECTIVE
THE BALANCED TOUCH OF THE URBAN PERSPECTIVE
PRODUCT DESCRIPTION
COOL-LITE® KN 166 II is a to-be-tempered version, delivered on standard with EASYPRO® unique temporary surface protection.
COOL-LITE® KN 166 A&T can be used either annealed or heat-treated, depending on the requirements of the building in which it is integrated. Heat-treated or not, performances and aesthetics are however different
BENEFITS & APPLICATIONS
COOL-LITE® KN 166 II & KN 166 A&T AMBIANCE are sustainable products that create comfortable interiors during both summer and winter.
- Aesthetic: Modern appearance and good light transmission, for an enhanced urban comfort.
- Energy efficiency: it brings solar protection at all times combined with well-balanced luminosity on every floor and reinforced thermal insulation. Heating and air-conditioning systems can be reduced to a minimum.
COOL-LITE® KN 166 II & KN 166 A&T AMBIANCE are perfectly adapted to both non-residential applications (office buildings, stores or showrooms, façades, skylights, etc.), and residential buildings. Due to the great balance of all technical performances, it represents a right choice for all projects, which require both modern design and great functionality.
APPEARANCE
COOL-LITE® KN 166 II & KN 166 A&T AMBIANCE have neutral aesthetic with a slight grey-silver nuance.
TECHNICAL INFORMATION
RANGE
SUBSTRATE: PLANICLEAR® (clear glass)
DIAMANT® (extra clear glass)
THICKNESS: From 6mm to 10mm
SIZE: Standard size (Jumbo 3.21 x 6.00 m)
Standard stock size
PROCESSING
- HEAT-TREATMENT:
- COOL-LITE® KN 166 II is a to-be-tempered product; It is delivered in standard with EASYPRO® temporary surface protection. To achieve its performance and aesthetics, the product must be tempered. It is compatible with Heat Soak Test.
- COOL-LITE® KN 166 A&T can be used either annealed or heat-treated,when used heat-treated or not, performances and aesthetics of the two products are different and it’s not recommended to mix them on the same façade.
- EDGE DELETION: Edge deletion of the coating is compulsory prior to assembling.
- INSULATED GLAZING UNIT: The products must be assembled into an insulated glazing unit (IGU); The coating must be positioned on the face 2 (inside the IGU).
- LAMINATION: The product can be laminated, taking care to place the coating outside of the laminate (coating on face 4 of the laminated pane). Consult us for the list of coating validated in contact with the interlayer.
- BENDING: The to-be-tempered version of the product (II) can be bent. Bending results depend on the process/technology used; trials should be done for validation.
- ENAMELING: No common approval for the enameling of silver-based high-performance coatings.
AVAILABILITY
The product is available WORLDWIDE.
PERFORMANCE
Looking for more configurations? Go to our online glazing configurator: www.calumen.com
