COOL-LITE® KS 146 II
PRODUCT DESCRIPTION
COOL-LITE® KS 146 II is a to-be-tempered product, offering thus safety and numerous design possibilities; it can be combined with many Saint-Gobain Glass products for enhanced performance or new functions.
BENEFITS & APPLICATIONS
Thanks to its silver aesthetics, the product blends in well with different environments or, on the contrary, can be used to create differentiating facades in certain markets.
- Aesthetic: Silver reflective outer appearance, to blend in or stand out.
- Solar control: by allowing less than a third of the sun's heat to pass through at all times, it contributes to the comfort and energy efficiency of buildings.
COOL-LITE® KS 146 II is an ideal option for all types of facade, dedicated to both non-residential (office buildings, stores, hotels, restaurants, etc.), and residential usages with an outstanding visual result.
APPEARANCE
COOL-LITE® KS 146 II is offering a neutral aesthetic in transmission with silver reflections from outside.
TECHNICAL INFORMATION
RANGE
SUBSTRATE: PLANICLEAR® (clear glass)
PLANILUX® (clear glass)
DIAMANT® (extra clear glass)
THICKNESS: From 4mm to 10mm
SIZE: Standard size (Jumbo 3.21 x 6.00 m)
Standard stock size
PROCESSING
- HEAT-TREATMENT: The product is a to-be-tempered product; to achieve its performance and aesthetics, the product must be tempered. It is compatible with Heat Soak Test.
- EDGE DELETION: Edge deletion of the coating is compulsory prior to assembling.
- INSULATED GLAZING UNIT: The product must be assembled into an insulated glazing unit (IGU); The coating must be positioned on the face 2 (inside the IGU).
- LAMINATION: The product can be laminated, taking care to place the coating outside of the laminate (coating on face 4 of the laminated pane). Consult us for the list of coatings validated in contact with the interlayer.
- ENAMELING: No common approval for the enameling of silver-based high-performance coatings.
The product is available WORLDWIDE.
PERFORMANCE
Looking for more configurations? Go to our online glazing configurator: www.calumen.com
